CGTH5

Repeatability：±0.01(mm)

Ball Screw Lead：2/5/10/20(mm)

Maximum Speed (Horizontal)：≦109/≦273/≦538/≦1102(mm/s)

Maximum Speed (Vertical)：≦108/≦269/≦538/≦1093(mm/s)

Maximum Payload (Horizontal)：≦30/≦30/≦15/≦10(kg)

Maximum Payload (Vertical)：≦10/≦10/≦5/≦2.5(kg)

Rated Thrust：1147/459/229/115(N)

Stroke/Pitch ：50-800 / 50(mm)

*The maximum speed shown here is when software speed setting is 100%

* The maximum speed and maximum payload cannot exist at the same time . Please refer to diagram of Speed and payload curve before using.

* When the stroke is over 600 mm, the run-out of the ballscrew will occur. We recommend to low down the working speed under this circumstances.
