DGTY4

Repeatability：±0.01(mm)

Ball Screw Lead：2/6/12(mm)

Maximum Speed (Horizontal)：≦100/≦300/≦600(mm/s)

Maximum Speed (Vertical)：≦100/≦300/≦600(mm/s)

Maximum Payload (Horizontal)：≦25/≦20/≦12(kg)

Maximum Payload (Vertical)：≦8/≦5/≦2 (kg)

Rated Thrust：827/276/138(N)

Stroke/Pitch ：50-800 / 50 pitch (mm)

*The maximum speed shown here is when software speed setting is 100%

* If payload is near maximum ,it requires to collocate externally with auxiliary guideway for bearing radial load.
